3 Way Tipper 14x7 Tri Axle
$16 000.00
NEW MODEL
The price listed is for the trailer only. Options and accessories shown in the image are not included. *Subject to availability
Upgradeble to 4500kg*
Please choose
Spare Wheel and Tyre*
Please choose
Vertical Spare Wheel Bracket*
Please choose
Cargo Net*
Please choose
Trailer Lock*
Please choose
Canvas Cover*
Please choose
This product is a Pre Order
1
Save this product for later
3 Way Tipper 14x7 Tri Axle
This trailer features a Unique 3-Way Tipping Function, making it perfect for heavy-duty tasks and rugged Australian conditions. With a massive capacity and the option to upgrade to a 4.5-ton rating, it’s ready for anything. The 600mm high removable heavy-duty cage and extra-long ramps, stored underneath, make loading equipment like ride-on mowers and tractors easy. Built tough with 60mm solid axles, 9-leaf roller rocker springs, and a durable 4mm checker plate floor, it handles heavy loads effortlessly. Farmers, tradies, and machinery operators will love this hardworking, versatile trailer!
| Model | 3 Way Tipper Tandem 14x7 |
| ATM | 3500kg Upgradable to 4500kg |
| Axle | Tri Axle 60mm Solid Square |
| Battery | 12V Automative Battery comes with Hydraulic System with Anderson cable installed for automatic charging from tow vehicle (tops up battery as you drive!) |
| Body | Unique 3-Way Tipping Function Hot Dip Galvanized (Rust Free) Tie Down Rails the Full Length of Deck Fully Welded Body and Chassis Storage for Ramps Under Deck |
| Brake | 12" Electric Drum Brake Electric Emergency Brake-Away Unit Fitted Manual Cable Parking Brake |
| Cage | Opening Removable 600 mm High Heavy Duty Perimeter Cage |
| Chasis | 150mm x 50mm x 4mm Box Section Used on Drawbar and Main Chassis Strongest Cross Brace Chassis Design Available |
| Coupling | 50mm Australian Standard |
| Drawbar | 1920mm x 100mm x 50mm x 6mm |
| Flooring | 2.5mm Checker-Plate Floor |
| Jockey Wheel | Heavy Duty Swing Up |
| Light Plug | Flat 7 Pin Plug |
| Lights | Tail Light Marker Light LED |
| Ramps | Two Heavy Duty Ramps for fitting Machinery (1-ton rating each) |
| Safety Chain | 2 x 12mm |
| Sides | Opening Removable Tail Gate and Drop Sides Checker Plate 400mm |
| Spare Wheel and Holder | Optional |
| Spring | 9 Leaf Heavy Duty 4.5ton Rated Springs |
| Tipping | Tip to the Rear, Tip to the Left or Tip to the Right Wireless Remote & Wired Remote for Tipping 10ton Five Stage Hydraulic Ram |
| Toolbox | Custom Toolbox for Hydraulic System |
| Wheels and Tyres | Light Truck Tyres Landcruiser Rims Mudflaps |
| Warranty | 12 Months Structural Warranty |
* Just a heads-up – the product might look a touch different from the pics 'cause of upgrades or how it’s displayed.
