Car and Machinery Carrier Hydraulic 16ft
The ultimate solution for hassle-free loading, this 3500kg galvanized hydraulic trailer eliminates the need for ramps. Its innovative design ensures quick loading and unloading, with wheel arches just 175mm above the deck for unobstructed car door access.
With a 2500kg payload and 2000mm clearance between mudguards, it easily accommodates most vehicles. A 12,000lb electric winch, housed in the trailer deck, enhances efficiency, making it ideal for transporting cars and machinery.
| Model | Car and Machinery Hydraulic Tilting Ramp Less Trailer 3.5ton |
| ATM | 3500kg TARE 1000kg Payload 2500kg Option Upgradable to 4500kg TARE 1100kg Payload 3300kg |
| Axle | Dual Axle 50mm Solid Square |
| Bearings | Heavy Duty DEXTER Wheel Bearings 4400kg Rated |
| Body | Hot Dip Galvanized (Rust Free) Fully Welded Body and Chassis Under Body extra Bracing with Long Lasting Construction No Heavy Ramps Required, Easy Efficient, Fast Loading |
| Brake | 12" Electric Drum Brake Electric Emergency Brake-Away Unit Fitted Manual Cable Parking Brake |
| Chassis | 125mm x 55mm Structural Chassis Super Strong and Flexible |
| Coupling | 50mm Quick Release Australian Standard |
| Deck Size | 5.0m x 2.0m (16.6 x 6ft) Clear of any Obstacles |
| Drawbar | 1920mm x 125mm x 55mm C Section |
| Jockey Wheel | Swing Up Twin 8inch Extra Heavy Duty Jockey Wheel 1200kg |
| Light Plug | Flat 7 Pin Plug |
| Lights | Multi Volt 12/24 LED Tail Light Marker Light |
| Ramps | Hydraulic Ramp with Push Button Controls for Ease of Loading |
| Safety Chain | 2 x 12mm |
| Spare Wheel and Holder | Included |
| Spring | Rocker Roller Suspension 9 Leaf Heavy Duty 4.5ton Rated Springs |
| Tie Down Points | Fold Down Tie Down Points 12 in Total 6 along each Sides in C-Section Channel foe Straps or Chains |
| Toolbox | Steel Toolbox on Drawbar Houses Hydraulic Pump, Electric Motor and Deep Cycle Battery |
| Winch | Integrated Winch Box 12,000lb (6 ton) Electric Winch with Wireless Remote and Wired in Remote |
| Wheels and Tyres | Light Truck Tyres 3 mm Thick Black Rims Mudflaps |
| Wheel Guards | 165mm above the Trailer Deck Eliminating Door Damage to Vehicles |
| Warranty | 12 Months Structural Warranty |
* Just a heads-up – the product might look a touch different from the pics 'cause of upgrades or how it’s displayed.
